Product Info
- Manufacturer:Allen-Bradley
- Sub-Category:Molded Case
Description
140MT-C3E-B16
140MT-C3E-B16 is an Allen-Bradley motor protection circuit breaker designed for reliable motor load protection with adjustable current settings.This C Frame motor protection breaker features an adjustable thermal trip range of 1 to 1.6 amps, Class 10 trip rating for fast response, and standard magnetic trip fixed at 14 times the rated current. It mounts easily on a 35MM DIN rail and includes screw terminals for secure wiring. Compatible with Allen-Bradley 100-C contactors, it supports front and side auxiliary mounting for signaling options. Rated for 480V supply voltage, it provides standard breaking capacity suitable for typical motor protection applications.
- Key Specifications
- Amperage Range: 1 to 1.6 Amps adjustable
- Voltage Rating: 480V AC, 60Hz
- Poles: 3 Pole
- Mounting Type: 35MM DIN Rail
- Trip Class: 10 (trips in 10 seconds or less)
- Frame Size: C Frame
- Interrupt Rating: Standard breaking capacity
- Trip Unit: Adjustable thermal, fixed magnetic trip (14x rated current)
- Terminals: Screw type
- Auxiliary Contacts: Front and side mount available
- Compatible with Allen-Bradley 100-C contactors
- Part Number: 140MT-C3E-B16
- Manufacturer : Allen-Bradley
- Brand : Allen-Bradley
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- UPC : 191326561853
- GTIN : 191326561853
- Weight : 1
