140MG-G8P-D10 - Allen-Bradley 100A 3-Pole G-Frame Motor Protector Circuit Breaker Magnetic Trip 65kA 600V AC

140MG-G8P-D10

140MG-G8P-D10 is a 3-pole motor protector circuit breaker from Allen-Bradley designed for adjustable magnetic short-circuit protection in motor circuits up to 100 amps.This G-Frame Bulletin 140MG motor circuit protector features a magnetic-only trip unit adjustable from 70 to 100 amps, suitable for industrial motor control applications. It supports up to 600V AC and has a high interrupt rating of 65 kA at 480V, ensuring reliable short-circuit protection. The breaker includes visible trip indication and can be equipped with auxiliary contacts and shunt trips for enhanced control and monitoring.

Key Specifications
• Amperage: 100 A
• Voltage Rating: 600 V AC
• Poles: 3
• Frame Size: G-Frame (125 A max)
• Trip Unit: Adjustable Magnetic Only
• Magnetic Trip Range: 70–100 A
• Interrupt Rating: 65 kA at 480 V
• Mounting Type: Panel Mount
• Certifications: UL/CSA Recognized
• Auxiliary and Alarm Contacts Available
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: 140MG-G8P-D10
• Manufacturer : Allen-Bradley
• Brand : Allen-Bradley
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic



Product Data

• UPC : 885630441979
• Weight : 5
