Product Info
- Manufacturer:Allen-Bradley
- Sub-Category:Molded Case
Description
140M-C2E-A63
140M-C2E-A63 is a motor protection circuit breaker from Allen-Bradley designed for motor branch circuit protection with adjustable thermal-magnetic trip settings ranging from 0.40 to 0.63 amps.
This 3-pole circuit breaker features a C frame size and DIN rail mounting with rotary operation. It provides short-circuit protection with a breaking capacity of 100 kA at 400 V AC and includes visible trip indication for easy fault identification. The breaker is UL and cULus listed for motor controller applications and complies with NEC/CEC requirements for motor branch circuit protection. It is suitable for use with 600 V AC systems and offers manual switching and magnetic trip fixed at 13 times the rated current.
- Amperage range: 0.40 - 0.63 A adjustable
- Voltage rating: 600 V AC
- Poles: 3
- Frame size: C
- Mounting type: DIN rail
- Interrupt rating: 100 kA at 400 V AC
- Trip unit: Thermal-magnetic, Class 10
- Operation: Rotary handle
- UL and cULus listed for motor controller applications
- Visible trip and short circuit trip indication
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: 140M-C2E-A63
- Manufacturer : Allen-Bradley
- Brand : Allen-Bradley
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Bulletin 140M
- Voltage : 600
- Amperage : 0.63
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : I - Instantaneous
- Protection : Magnetic Only
Product Data
- Weight : 5
