140G-G6C3-D10 - Allen-Bradley 100A 3-Pole Molded Case Circuit Breaker G Frame

140G-G6C3-D10

140G-G6C3-D10 is an Allen-Bradley molded case circuit breaker designed for industrial and commercial power distribution applications requiring high interrupting capacity and reliable thermal-magnetic protection.

This G-frame circuit breaker features fixed thermal and fixed magnetic trip protection with a rated current of 100 amperes at 40 degrees Celsius. The device delivers a 65 kA interrupting rating at 480 volts AC and supports operational voltages up to 690 volts AC or 500 volts DC. With a thermal trip setting of 100 amps and magnetic trip setting of 1000 amps, it provides comprehensive overcurrent and short-circuit protection. The breaker is factory-assembled and ready for bolt-on installation in standard panelboards.

• Rated Current: 100 A at 40 degrees Celsius
• Number of Poles: 3
• Frame Size: G Frame, 125 A maximum
• Protection Type: Fixed Thermal-Magnetic
• Interrupting Rating: 65 kA at 480V AC
• Rated Insulation Voltage: 800 V
• Operating Voltage Range: 220-690V AC, 500V DC maximum
• Thermal Trip: 100 A
• Magnetic Trip: 1000 A
• Mounting: Bolt-On
• Assembly: Factory Assembled
• Dimensions: 76.2 mm W x 130 mm H x 70 mm D
• Weight: 2.42 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 140G-G6C3-D10
• Manufacturer : Allen-Bradley
• Brand : Allen-Bradley
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Bulletin 140G
• Type : 140G
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : G Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 885630446134
• GTIN : 00885630446134
• Weight : 1
