12SKLSJ125
12SKLSJ125 is a Eaton Bussmann Class J fast-acting fuse rated for 125 amperes and 600 volts AC.
This fuse features a single-element design with a bolted blade end connection style and a non-indicating fuse indicator. It is a current-limiting fuse with an interrupt rating of 200 kAIC at 600 volts AC, suitable for protecting electrical circuits against overloads and short circuits. The fuse body is made of melamine and designed for bolt-on mounting. It complies with UL 248-8 and CSA Class 1422-02 standards.
- Key Specifications
- Amperage Rating: 125 A
- Voltage Rating: 600 V AC
- Interrupt Rating: 200 kAIC at 600 V AC
- Fuse Class: Class J
- Fuse Speed: Fast-Acting
- Number of Elements: 1
- Connection Type: Bolted blade end x bolted blade end
- Fuse Indicator: Non-indicating
- Body Material: Melamine
- Mounting Type: Bolt-On
- Standards: UL 248-8, CSA Class 1422-02
- Part Number: 12SKLSJ125
- Manufacturer : Edison||Bussmann
- Brand : Edison
- Category : Fuse
- Item Subcategory : Medium Voltage
- Voltage : 12000
- Amperage : 125
- AIC rating : 50kA@12kV
- Connection : Ferrule
- Diameter : 3
- Class Rating : J
- Barrels : 1
- Weight : 4
