Product Info
- Manufacturer:Eaton
- Sub-Category:Automation Switch
Description
10316H185
10316H185 is an Eaton hazardous location limit switch designed for extreme environmental service with a side rotary actuator and durable die cast zinc enclosure.10316H185 features a contact rating of 10A at 600Vac and 0.22A at 125Vdc, with a contact configuration of 1 normally open (NO) and 1 normally closed (NC). It uses screw terminal connections and is rated for NEMA 1, NEMA 4, and NEMA 13 environments, suitable for hazardous locations requiring robust protection.
- Contact Rating: 10A at 600Vac, 0.22A at 125Vdc
- Contact Configuration: 1 NO - 1 NC
- Switch Type: Side Rotary
- Enclosure Material: Die Cast Zinc
- Connection Type: Screw Terminal
- Environmental Rating: NEMA 1, NEMA 4, NEMA 13
- Operating Temperature Range: -20°F to 200°F
- Product Dimensions: 3.88 in W x 2.25 in H x 1.55 in D
- Product Weight: 1.125 lb
Specifications
- Part Number: 10316H185
- Manufacturer : Eaton
- Brand : Eaton
- Category : Automation
- Item Subcategory : Automation Switch
- Section : Limit Switch
Product Data
- UPC : 078211322900
- GTIN : 00782113229003
- Dimensions : 1.55 in x 2.25 in x 3.88 in (Length/Depth x Height x Width)
- Weight : 1.125
