Product Info
- Manufacturer:Eaton
- Sub-Category:Parts & Accessories
Description
10316H1028
10316H1028 is a precision cabinet door interlock limit switch with a red defeated indicator, designed for reliable safety interlock applications. This Eaton switch features a 1NO-1NC snap action configuration and screw terminal connections for secure wiring. The Eaton 10316H1028 is engineered for panel mounting and provides precise actuation for cabinet door interlock systems. It offers a robust design with a durable plunger and clear visual indication of the defeated (red) status. The switch is suitable for use in industrial control panels and safety circuits where reliable operation is critical.
- 1NO-1NC snap action contact configuration
- 20A make at 240 Vac, 0.2A at 240 Vdc
- 40A make, 15A break maximum AC current
- 0.2A make, 0.2A break maximum DC current
- Screw terminal connection
- Precision switch mechanism
- Red defeated indicator
- Panel mounting type
- CSA Certified
- UL Listed
Specifications
- Part Number: 10316H1028
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Switch
- Item Subcategory : Parts & Accessories
- Compatible Frames : TJJ
Product Data
- UPC : 782113320915
- GTIN : 00782113320915
- Country of Origin : Mexico
- Dimensions : 3.19 in x 2.6 in x 1.03 in (Length/Depth x Height x Width)
- Weight : 0.35
- Certification : CSA Certified,UL Listed
