10250TA75 - Eaton 30mm Flush Head Heavy Duty Pushbutton 10A 600VAC/DC NEMA 3R/4X

10250TA75

10250TA75 is an Eaton heavy-duty pushbutton operator designed for industrial control stations with a 30.5 mm flush-mount configuration. This mechanically interlocked pushbutton features a contact rating of 10A at 600V AC/DC and is constructed with zinc die-cast housing and plastic actuators in green and black colors. The unit is rated for NEMA 3, 3R, 4, 4X, 12, and 13 enclosures with IP65 protection against oil, water, and grease. It operates in a maintained action mode with push-to-release functionality and includes reliability nibs to ensure consistent contact performance even under dry circuit conditions.

• Contact Rating: 10A @ 600V AC/DC
• Mounting Type: Flush
• Frame Size: 30.5 mm
• Actuator Material: Plastic
• Head Material: Metal (Chrome)
• Operator Colors: Green, Black
• NEMA Ratings: 3, 3R, 4, 4X, 12, 13
• IP Rating: IP65
• Operating Mode: Maintained
• Mechanical Interlock: Yes
• Certifications: UL Listed, CSA Certified, CE Marked
• Operating Temperature Range: 1°F to 150°F

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 10250TA75
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Automation
• Item Subcategory : Pilot Device/Push Button
• Family : 10250T Series
• Type : 10250T

Product Data

• UPC : 78211334684
• GTIN : 00782113346847
• Country of Origin : Dominican Republic
• Dimensions : 4.3 in x 3.4 in x 3.2 in (Length/Depth x Height x Width)
• Weight : 0.7 lb
• Certification : UL Listed,CSA Certified,CE Marked
