HDA260452 - Square D PowerPact H-Frame 45A 2-Pole 600V 14kAIC Thermal Magnetic Molded Case Circuit Breaker, I-Line Panelboard Mount, UL/CSA/CE Certified

HDA260452

HDA260452 is a Square D PowerPact H-Frame molded case circuit breaker designed for reliable protection in industrial and commercial electrical systems.

This thermal magnetic, current-limiting circuit breaker features a robust design for I-Line panelboard and switchboard applications, offering high interrupting capacity and compliance with major safety standards.

• Amperage: 45A
• Voltage: 600V AC
• Poles: 2
• Mounting Type: I-Line panelboard and switchboard
• Interrupt Rating: 14kAIC at 600V, 18kAIC at 480V
• Series/Frame: PowerPact H-Frame (HDA)
• Trip Unit: Thermal magnetic
• Certifications: UL, CSA, CE
• Application: Class 611/612 I-Line panelboard and switchboard
• Type: Molded case, current limiting
• Phase: AC
• Features: Suitable for reverse fed applications, industrial grade

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDA260452
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 45
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901632535
• GTIN : 00785901632535
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
