Product Info
- Manufacturer:General Electric
- Sub-Category:Motor Starter
Description
CR306CXH002BAT
CR306CXH002BAT is a General Electric non-reversing motor starter designed for industrial motor control applications with full voltage capability up to 600 VAC. This NEMA Size 1 starter features a 3-pole configuration with a 120 VAC coil and is rated for 27 amps continuous duty. CR306CXH002BAT combines reliable magnetic switching technology with thermal overload protection to safeguard motors against phase imbalances and overload conditions. The open-frame design allows for flexible mounting in control enclosures and panels. This starter is suitable for controlling motors up to 10 hp at 460/480V or 575/600V three-phase operation.
- Manufacturer: General Electric
- Part Number: CR306CXH002BAT
- Poles: 3
- Frame Size: CR306, NEMA Size 1
- System Voltage: 600 VAC
- Coil Voltage: 120 VAC
- Continuous Amperage Rating: 27 A
- Enclosure Type: Open
- Overload Protection: Thermal 3-leg relay
- Mounting: Surface
- Weight: 4 lbs
Specifications
- Part Number: CR306CXH002BAT
- Manufacturer : General Electric
- Brand : General Electric
- Category : Motor Control
- Item Subcategory : Motor Starter
Product Data
- UPC : 786679683828
- Weight : 4
