454001R1 - S&C Electric 34.5 kV SMD-1A Slow Fuse for Outdoor Distribution

454001R1

454001R1 is a 34.5 kV SMD-1A slow fuse designed by S&C Electric for outdoor distribution applications.

This fuse provides reliable, high-speed fault interruption with a slow-blow characteristic suitable for transformer protection and other substation uses. It features a solid-material-lined bore that enables fast arc elongation and efficient deionizing gas action, ensuring positive fault clearing. The fuse is part of the SMD series, rated for 34.5 kV nominal voltage, and is engineered to handle continuous currents up to 200 amperes with an interrupting rating suitable for typical distribution system fault currents. It mounts using standard hardware compatible with terminal pads and is designed for use in solidly grounded-neutral systems.

• Voltage Rating: 34.5 kV nominal
• Fuse Type: SMD-1A
• Speed: Slow
• Continuous Current Rating: Up to 200 amperes
• Interrupting Rating: Suitable for typical distribution fault currents (up to 25,000 amperes RMS symmetrical at system voltages above 15.5 kV)
• Mounting: Standard galvanized steel hardware for terminal pad attachment
• Application: Outdoor distribution and substation transformer protection
• Construction: Solid-material-lined bore for fast arc elongation and deionizing action
• Series: SMD Power Fuse Series
• Certifications: Manufactured under ISO 9001 quality system

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 454001R1
• Manufacturer : S&C Electric
• Brand : S&C Electric
• Category : Fuse
• Item Subcategory : Medium Voltage
• Type : SMD-1A
• Voltage : 34500
• Amperage : 1
• Class Rating : SMD-1A
• Velocity : Slow

Product Data

• Weight : 10
